T54
vPolyTanTM Solid Tantalum Surface Mount Chip Capacitors,
Multianode, Leadframeless Molded Polymer Type,
Commercial Off-The-Shelf (COTS)
- Ultra-low ESR
- Molded case 7343 EIA size
- Terminations: wraparound
- 12 mm tape and reel packaging available per EIA-481 standard
- Moisture sensitivity level 3
Applications
- Decoupling, smoothing, filtering
- Switch mode and point of load power supply
- Infrastructure equipment
- Storage and networking
T97
Solid Tantalum Chip Capacitors TANTAMOUNT®,
Hi-Rel COTS, Ultra-Low ESR,
Conformal-Coated Case
- High-reliability; Weibull failure rate grading available
- Surge current testing per MIL-PRF-55365 options available
- Ultra-low ESR
- Tin/lead (SnPb) terminations available
- Mounting: surface-mount
Performance Characteristics
- Capacitance Range: 10 μF to 1500 μF
- Capacitance Tolerance: ± 10 %, ± 20 % standard
- Voltage Rating: 4 VDC to 75 VDC
HE5
Wet Tantalum Capacitors, High Energy,Ultra High Capacitance,
-55 °C to +125 °C Operation
- High energy, very high capacitance design
- All tantalum, hermetically sealed case
- Utilizes Vishay proven SuperTan® technology
- Terminations: radial leaded
Applications
- Industrial
- Avionics / military / space
ST/STE
SuperTan® Wet Tantalum Capacitors with Hermetic Seal
- Very high capacitance
- 10 μF to 1800 μF
- 25 VDC to 125 VDC
- Very low ESR• High ripple current
- All tantalum case
- Hermetically sealed
- Low DCL
- Axial through-hole terminations: standard tin / lead (Sn / Pb), 100 % tin (RoHS compliant) available
Performance Characteristics
- Operating Temperature: -55 °C to +85 °C (to +125 °C with voltage derating)
- Capacitance Tolerance: at 120 Hz, +25 °C.± 20 % standard. ± 10 % available as special.
T22
Wet Tantalum SMD Capacitors, Tantalum Metal Case with Glass-to-Tantalum Hermetic Seal
Features
- Enhanced performance, high reliability design
- SMD, standard tin / lead (Sn / Pb), 100 % tin (RoHS-compliant) available
- Mounting: surface-mount
- Increased thermal shock capability of 300 cycles
- Designed for the avionics and aerospace applications
T18
Wet Tantalum Capacitors, Ultra High Capacitance, Tantalum-Case with Glass-to-Tantalum Hermetic Seal for -55 °C to +125 °C
Features
- Enhanced performance, high reliability design
- Terminations: axial, standard tin / lead (SnPb), 100 % tin available
- Model T18 tantalum-case electrolytic capacitors provide all the advantages of Vishay’s SuperTan® series devices, while offering improved reverse voltage and vibration capability
- Increased thermal shock capability of 300 cycles
- Designed for the avionics and aerospace applications
T25
Solid Tantalum SMD Capacitors TANTAMOUNT™,Hi-Rel COTS, Low ESR, Metal Case
- High reliability; burn-in at a minimum of rated DC voltage for a minimum of 40 h
- Surge current testing per MIL-PRF-55365option available
- Low ESR
- Lead (Pb)-free terminations available (tin / lead terminations are under development)
- Mounting: surface mount
- Material categorization: for definitions of compliance please see www.vishay.com/doc?99912
M39006/33
Wet Tantalum Capacitors, Extended Capacitance,Military Established Reliability
Features
- Hermetically sealed
- Tantalum cased
- Axial lead
- Tubular
Applications
- Industrial
- Avionics / space
