246 CTI-V
Aluminum Electrolytic Capacitors
SMD (Chip), High Temperature, Low Impedance,
High Vibration Capability
Features
- Extended useful life: up to 6000 h at 125 °C
- Polarized aluminum electrolytic capacitors, non-solid electrolyte, self healing.
- SMD-version with base plate, lead (Pb)-free reflow solderable.
- Charge and discharge proof, no peak current limitation.
- Advanced temperature reflow soldering according to JEDEC® J-STD-020
- Vibration proof, 6-pin version up to 30g.
- AEC-Q200 Qualified
- High reliability
- Low ESR
Applications
- SMD technology, for high temperature reflow soldering
- Industrial and professional applications
- Automotive, general industrial, telecom
- Smoothing, filtering, buffering
246 RTI-V
Aluminum Electrolytic Capacitors
Radial, High Temperature, Low Impedance,
High Vibration Capability
Features
- Very long useful life: 4000 h to 6000 h at 125 °C
- High stability, high reliability
- Very low ESRAEC-Q200 qualified
- Excellent ripple current capability
- High vibration resistance up to 50 g
- Polarized aluminum electrolytic capacitors, non-solid electrolyte
- Radial leads, cylindrical aluminum case, insulated with a blue PET sleeve
- Charge and discharge proof
Performance Characteristics
- Power supplies (SMPS, DC/DC converters) for industrial, automotive, telecommunications and military
- Smoothing, filtering and buffering
260 CLA-V
Aluminum Electrolytic Capacitors
SMD (Chip), High Temperature, Low Impedance
High Vibration Capability
Features
- Useful life: up to 2000 h at 150 °C
- High reliability
- Low ESR
- Polarized aluminum electrolytic capacitors, non-solid electrolyte, self healing
- SMD-version with base plate, lead (Pb)-free reflow solderable
- Charge and discharge proof, no peak current limitation
- High temperature reflow soldering according to JEDEC® J-STD-020
- High temperature proof
- Vibration proof, 6-pin version up to 30 g
- AEC-Q200 qualified
Applications
- SMD technology, for high temperature reflow soldering
- High temperature environment, high peak load
- Automotive, industrial
- Smoothing, filtering, buffering
MKP1848 DC-Link
Metallized Polypropylene Film Capacitors
DC-Link Capacitor
Features
- High performance DC filter
- Low ESR
- High peak current capabilities
- High RMS current capabilities
- AEC-Q200 qualified
- Mounting: radial
Applications
- High performance DC filtering
- HEV / EV: i.e. power train and OBC
- Renewable energies inverters
- Motor drives
- Power supplies
MKP1848C DC-Link
Metllized Polypropylene Film Capacitor
DC-Link Capacitor
Features
- High density DC-link capacitor (more C per volume)
- Very long useful life time: Up to 100 000 h at UNDC and 70 °C
- High ripple current capability, low ESR, low ESL
- Temperature range: 105 °C
- Mounting: radial
Applications
- Renewable energies inverters
- UPS
- Battery Charges
- Motor drives
MKP1848S DC-Link
Metallized Polypropylene Film Capacitors
DC-Link Capacitor
Features
- Slim line, low building height
- Very long useful life time: Up to 100 000 h at UNDC and 70 °C
- High ripple current capability, low ESR, low ESL
- Temperature range: 105 °C
- Mounting: Radial
Applications
- PV micro inverters
- LED street lighting
- On board chargers (EV/HEV), battery chargers
MKP1847H AC Filtering
THB AC Filtering Metalized Polypropylene Film Capacitor
Radial Type 85 °C / 85 % RH 1000 h at UNAC
Features
- High robustness under high humidity
- THB 85 °C, 85 % RH, 1000 h at rated UNAC
- Segmented film
- Material categorization: for definitions of compliance please see www.vishay.com/doc?99912
Applications
- Outdoor applications
- UPS systems
- Renewable energy
- AC harmonic filter
- Welding equipment
MKP386M Snubber
Metallized Polypropylene Film Capacitor
Radial Snubber Type
Features
- Reduce EMI by clamping voltage and current ringing
- High pulse strength (dV/dt up to 2500 V/μs)
- Low inductance construction (low ESL)
- Low ESR
Applications
- Photovoltaic and wind inverters
- Motor drives
- Frequency converters
- Direct mount on IGBT modules
Product Guide
MKP339 X2
Interference Suppression Film Capacitors
MKP Radial Potted Type
Features
- AEC-Q200 qualified
- 7.5 mm to 27.5 mm lead pitch
- Supplied loose in box, taped on ammopack or reel
Applications
- For standard across the line X2 applications.
Product Guide
AY2
Automotive Grade AC Line Rated Ceramic Disc Capacitors
Class X1, 440 VAC, Class Y2, 300 VAC
Features
- AEC-Q200 qualified
- Can pass 3000 temperature cycles (from -55 °C to +125 °C)
- Complying with IEC 60384-14 3rd edition
- High-reliability
- Vertical (inline) kinked or straight leads
- Singlelayer AC disc safety capacitors
- PPAP (AIAG version) is available
Applications
- X1, Y2 according to IEC 60384-14.3
- Application as Y capacitors for AC line filter and primary-secondary coupling on battery chargers for PHEV/EV
- Application as filter capacitors on DC/DC converters for PHEV/EV and HEV
VY1
AC Line Rated Ceramic Disc Capacitors
Class X1, 760 VAC, Class Y1, 500 VAC
Features
- Complying with IEC 60384-14 3rd edition
- High-reliability
- Vertical (inline) kinked or straight leads
- Single layer AC Disc safety capacitors
Applications
- X1, Y1 according to IEC 60384-14.3
- Across-the-line
- Line by-pass
- Antenna coupling
K...H Series
High Operating Temperature Radial Leaded Multilayer Ceramic Capacitors for Automotive Applications, 50 VDC, 100 VDC,
200 VDC
Features
- AEC-Q200 qualified with PPAP available
- High-reliability MLCC insert with wet build process
- High operating temperature up to 175 °C
- High capacitance with small size
- Radial mounting style
- Crimp and straight lead styles
Applications
- Automotive applications up to 175 °C
