246 CTI-V
Aluminum Electrolytic Capacitors
SMD (Chip), High Temperature, Low Impedance,
High Vibration Capability
Features
- Extended useful life: up to 6000 h at 125 °C
- Polarized aluminum electrolytic capacitors, non-solid electrolyte, self healing.
- SMD-version with base plate, lead (Pb)-free reflow solderable.
- Charge and discharge proof, no peak current limitation.
- Advanced temperature reflow soldering according to JEDEC® J-STD-020
- Vibration proof, 6-pin version up to 30g.
- AEC-Q200 Qualified
- High reliability
- Low ESR
Applications
- SMD technology, for high temperature reflow soldering
- Industrial and professional applications
- Automotive, general industrial, telecom
- Smoothing, filtering, buffering
246 RTI-V
Aluminum Electrolytic Capacitors
Radial, High Temperature, Low Impedance,
High Vibration Capability
Features
- Very long useful life: 4000 h to 6000 h at 125 °C
- High stability, high reliability
- Very low ESRAEC-Q200 qualified
- Excellent ripple current capability
- High vibration resistance up to 50 g
- Polarized aluminum electrolytic capacitors, non-solid electrolyte
- Radial leads, cylindrical aluminum case, insulated with a blue PET sleeve
- Charge and discharge proof
Performance Characteristics
- Power supplies (SMPS, DC/DC converters) for industrial, automotive, telecommunications and military
- Smoothing, filtering and buffering
260 CLA-V
Aluminum Electrolytic Capacitors
SMD (Chip), High Temperature, Low Impedance
High Vibration Capability
Features
- Useful life: up to 2000 h at 150 °C
- High reliability
- Low ESR
- Polarized aluminum electrolytic capacitors, non-solid electrolyte, self healing
- SMD-version with base plate, lead (Pb)-free reflow solderable
- Charge and discharge proof, no peak current limitation
- High temperature reflow soldering according to JEDEC® J-STD-020
- High temperature proof
- Vibration proof, 6-pin version up to 30 g
- AEC-Q200 qualified
Applications
- SMD technology, for high temperature reflow soldering
- High temperature environment, high peak load
- Automotive, industrial
- Smoothing, filtering, buffering
